GraphPad Pro is a touch based engineering drawing application specifically designed for contractors who need to make accurate dimensional drawings while in the field. Sketch a design and GraphPad will snap the lines into alignment and leave you with a discrete set of points to work with. Round corners and add drill holes with the exact radius. Add dimensions and translate lines to accurately capture precise measurements. Finish your design by adding pictures, symbols and text; then email it to clients and co-workers while still on-site.
In addition to having the best 2D dimensional drawing engine for the iPad, GraphPad can be configured with multiple complex multipage forms. Add all your sales forms and proposals along with a library of all your standard symbols and GraphPad becomes an indispensable tool for your salesmen. Draw up a site drawing while having a conversation with your customer, complete your entire sales proposal right on the iPad and even capture your customers signature! Email your completed contract directly from the iPad, automatically blind copying your office and you can complete your sale on the first visit!
GraphPad – Engineering drawing made easy!
List of features:
General Drawing features:
Creates straight lines with angle snap
Creates continuous smooth curves
New line starting end point automatically snaps to the grid
Angle snap user settable (Off, 10,30,45 Degrees)
Supports English inches, feet, yards and miles
Supports Metric millimeters, centimeters, meters and kilometers
Supports scale multiples of 1/100, 1/10, 1, 10, 100, 1000 of selected units
Scale slider allows easy scale from .5 - 10 times units
Create a dimension on an object with one touch
Supports line lengths, point to point, point to line and radius dimensions
Dimensions automatically adjust when the scale is changed
Objects of fixed dimensions automatically re-size when scale is changed
Features only available in GraphPad Pro
Calculate Areas of closed shapes
Calculate total line lengths of selected lines
Summary Table automatically totals items
Import images from the Photo Library
Import images from webpages, by copying them to the Photo Library
Rotate, scale and crop images
Set images to allow resizing, proportional resizing, or fixed size
Set images to allow or restrict rotation
Images rotate to the user specified angle snap
Display image dimensions for scaled images
Store an image or geometry in the user library
Stored images retain image properties on size, dimensions and rotation
Features only available in the Configurable version of GraphPad
Configuration (Consulting required)
Can be configured with your companies Forms and Library symbols
Add tables and calculations
Use a Mapview to display appointments (Consulting required).
Opening a form after selecting an appointment downloads and populates customer
data into your form (In-App purchased forms and Custom built).
